TF-ES2 electrical heating spray booth
TF-ES2 electrical heating spray booth
Note: picture is for reference only.
| Product name | electrical heating spray booth |
| Model name | TF-ES2 |
| Inside size | 6900 x 3900 x 2650 mm (L*W*H) |
| Outside size | 7000 x 5350 x 3400 mm (L*W*H) |
| Main door | 3 folds, 3000 x 2600 mm (W*H), aluminum alloy covered frame |
| Personal door | 1 fold, 650 x 1800 mm (W*H) |
| Wall panel | 50 mm EPS + 0.376 mm steel x 2 |
| Basement | galvanized steel assemble, height is 300mm, 2 rows of steel grills, 3 rows of diamond plates |
| Loading ramp | 2 ramps, 620 x 2000 mm each, diamond plate construction |
| Lighting | ceiling light: 24 pc x 16 w LED light, side light: optional |
| Inlet fan | 2 x 4 KW centrifugal fans, total air capacity: 25000 m3/h |
| Outlet fan | optional |
| Heating lamp | 30 pc x 1 kw infrared lamp |
| Filter system |
primary filter: capture granules larger than 10 μm, filtering rate >83% ceiling filter: capture granules later than 4 μm, filtering rate > 98% |
| Control system | Lighting switch, spraying, risen-temperature spraying, baking temperature controller, time setting, emergency stop indicator |
| Total power | 45 kw, 380V 3ph 50 hz |
