TF-ES3 electrical heating spray booth

TF-ES3 electrical heating spray booth


 Note: picture is for reference only.

Product name electrical heating spray booth
Model name TF-ES3
Inside size 6900 x 3900 x 2650 mm (L*W*H)
Outside size 7000 x 5350 x 3400 mm (L*W*H)
Main door 3 folds, 3000 x 2600 mm (W*H), aluminum alloy covered frame
Personal door 1 fold, 650 x 1800 mm (W*H)
Wall panel 50 mm EPS + 0.426 mm steel x 2
Basement galvanized steel assemble, height is 300mm, 5 rows of steel grills
Loading ramp 2 ramps, 900 x 2000 mm each, diamond plate construction
Lighting ceiling light: 24 pc x 16 w LED light, side light: 16 pc x 16 w LED light
Inlet fan 2 x 3 KW  centrifugal fans, total air capacity: 25000 m3/h
Outlet fan 1 x 5.5 KW  centrifugal fans, total air capacity: 16000 m3/h
Heating lamp 30 pc x 1 kw infrared lamp
Filter system primary filter: capture granules larger than 10 μm, filtering rate >83%
ceiling filter: capture granules later than 4 μm, filtering rate > 98%
Control system Lighting switch, spraying, risen-temperature spraying, baking temperature controller, time setting, emergency stop indicator
Total power 45 kw, 380V 3ph 50 hz
Note: Due to product improvement, design & specifications are subject to change without notice.
