CSB5004LB car spray booth with oil burner

CSB5004LB car spray booth with oil burner

AUTENF Car Spray Booth

Model AUTENF CSB5004LB
Inside dimension 6840 × 3900 × 2700mm (L × W × H)
Outside dimension 6940 × 5400 × 3450mm (L × W × H)
Main door 3 folds, 2800 × 2500mm (W × H)
Personal door 1 fold, 600 × 2000mm (W × H)
Wall panel 50 mm EPS
Lighting Ceiling light: 10 groups × 3 pieces, 36W per piece
Side light: 10 groups × 4 pieces, 36W per piece
Inlet fan 1 set of 7.5KW double-intake centrifugal fan, air capacity: 25000m 3 /h
Exhaust fan 1 set of 7.5KW double-intake centrifugal fan, air capacity: 25000m 3 /h
Heating system RIELLO RG5S oil burner, heating productivity: 260000Kcal/h
Filter system Intake air: Pre-filter, high efficiency ceiling filter
Exhaust air: fiberglass filter, exhaust activated carbon filter
Control system Lighting switch, spraying, risen-temperature spraying, baking temperature controller, time setting, time accumulator, emergency stop, differential pressure meter,  failure alarm
Total power 17.5KW
