TF-15 spot welder

Product name	spot welder
Model name	TF-15
Rated input voltage	220V
Input capacity	2.5 kVA/4.0 kVA
Rated duty cycle	50%/30%
No load voltage	1.6 V
Max. output current	<= 20 kA
Max. electrode pressure	1780 N
Welding thickness	0.5+0.5~1.5+1.5 mm
Insulation grade	H

Note: Due to product improvement, design and specifications are subject to change without notice.
